PSMV-OP-002 is an ultra-compact Pancake optical lens module specifically optimized for high-resolution Micro-OLED displays. Utilizing a folded optical path design, it significantly reduces the depth of near-eye optical assemblies while delivering crisp Full HD (FHD) image clarity across a comfortable ~60° Field of View (FOV).
Engineered to eliminate heavy optical bulk and distortion, PSMV-OP-002 serves as an ideal optical engine for high-immersion VR headsets, flight training simulators, and industrial near-eye display systems.
PSMV-OP-002 | FHD Compact VR Pancake Optical Engine
Key Technical Specifications
| Parameter | Specification | Engineering Focus |
| Product Code | PSMV-OP-002 | Pancake Optical Engine |
| Optical Architecture | Folded Pancake Lens System | Ultra-short optical path |
| Compatible Display | FHD Micro-OLED Series (e.g., PSMV-DP-012) | High-resolution micro-displays |
| Field of View (FOV) | Approx. 60° | Immersive near-eye view |
| Image Resolution | Supports Full HD (1080p) | Edge-to-edge optical clarity |
| Form Factor | Compact & Slim Structure | Low head-torque design |
Core Strengths & Features
- Folded Pancake Optics Architecture
- Drastically reduces lens barrel length, enabling sleek, lightweight head-mounted display designs.
- High-Clarity FHD Visual Experience
- Optimized polarization and lens coatings maintain high contrast and minimize ghosting or optical aberrations.
- Immersive 60° Field of View
- Delivers a balanced field-of-view tailored for training simulations and spatial computing applications.
Target Applications
- Virtual Reality (VR) Headsets: Compact immersive headsets, consumer VR optics, and enterprise HMDs.
- Training & Flight Simulation: Aviation simulators, tactical training visors, and virtual equipment operation equipment.
- Industrial & High-Resolution Near-Eye Displays: Diagnostic viewfinders, remote robot operation HMDs, and spatial visualization terminals.
