For conversion between interfaces, connectors and mechanical structures. Customizable based on display, carrier board and terminal structure requirements.
PSMV-BK-003 is a multi-functional interface adapter board engineered specifically for silicon-based Micro-OLED display modules and evaluation setups. Designed to facilitate seamless electrical, pinout, and mechanical interconnections, it bridges host controller boards with micro-display panels during prototyping, debugging, and system integration.
Serving as an essential hardware adapter, PSMV-BK-003 supports both TTL RGB and LVDS signal converting workflows. It provides a reliable interface bridge for initial screen bring-up, RGB signal verification, high-resolution image input, and custom industrial mainboard adaptation.
PSMV-BK-003 | Micro-OLED Interface Adapter Board
Key Technical Specifications
| Parameter | Specification | Functional Focus |
| Product Code | PSMV-BK-003 | Display Evaluation Accessory |
| Board Type | Adapter Board (转接板) | Connector & Mechanical Conversion |
| Signal Compatibility | TTL RGB / LVDS | Multi-protocol display signaling |
| Primary Function | Interface Bridge & Routing | Electrical & mechanical conversion |
| System Role | Evaluation & Debugging | Host-to-display interconnect |
Core Advantages & Features
- Flexible Signal & Mechanical Interconnect
- Solves pinout mismatched issues and simplifies routing between micro-display modules and host processors.
- TTL RGB & LVDS Signal Support
- Accommodates TTL RGB pipelines for basic display bring-up and image testing, as well as differential LVDS routing for noise-sensitive industrial controllers.
- Streamlined Prototype Testing
- Reduces development cycles by providing a plug-and-play connection interface for optical setups and hardware debugging.
Application & Integration Directions
- TTL RGB Workflows: Used for preliminary power-on testing, RGB signal integrity verification, and pattern generator connections.
- LVDS Workflows: Enables high-resolution video signal routing and custom integration with industrial control mainboards.
- Development & Assembly: Serves as an interposer board for mechanical fitting and optical test bench setups.
