PSMV-DP-005 is a high-definition 0.49-inch full-color silicon-based Micro-OLED (OLEDoS) display module designed for space-conscious optical engines. Built on a single-crystal silicon CMOS backplane, it delivers crisp 1280 × 720 (720p HD) visuals in a native 16:9 widescreen format, balancing micro-scale compactness with rich pixel density.
Featuring dual-interface support (MIPI / TTL), the PSMV-DP-005 offers high system adaptability for seamless connection to mobile processors, FPGAs, and compact video controllers. It provides exceptional contrast, high color fidelity, and sub-millisecond switching speeds, serving as a reliable HD micro-display platform for wearable AR optics, digital viewfinders, and portable inspection systems.
Key Technical Specifications
| Parameter | Specification | Notes / Details |
| Model Code | PSMV-DP-005 | HD Compact Microdisplay Module |
| Display Technology | Silicon-based Micro-OLED (OLEDoS) | Monolithic Silicon CMOS Architecture |
| Diagonal Size | 0.49 inch | High-definition compact footprint |
| Resolution | 1280 × 720 (720p HD) | Native HD pixel density |
| Aspect Ratio | 16:9 | Widescreen near-eye format |
| Color Mode | Full Color | High contrast & vivid saturation |
| Interface Support | MIPI DSI / TTL RGB | Flexible dual-interface option |
| Platform Category | HD Compact Display Source | Commercial & OEM integration |
Features
- Native 720p HD Image Precision
- Packs 1280×720 widescreen resolution into a 0.49″ footprint, delivering sharp textual and video clarity for optical magnification.
- Dual-Interface Versatility (MIPI / TTL)
- Simplifies integration by accommodating both low-pin-count MIPI streams and direct TTL digital video inputs.
- High-Efficiency Micro Footprint
- Silicon CMOS integration keeps module dimensions minimal, ideal for weight-sensitive wearable and handheld optical assemblies.
- Instantaneous Response Speed
- Eliminates dynamic blur and ghosting, maintaining clean image stability during motion.
Target Applications
- Augmented Reality (AR) Optics: Widescreen near-eye display engines, micro-HUD modules, and see-through optical combiners.
- Digital Viewfinders & Thermal Optics: Compact monocular/binocular viewfinders, thermal imagers, and optical rangefinders.
- Portable & Industrial Diagnostics: Wearable inspection displays, medical micro-viewers, and tactical command gear.
