PSMV-DP-015 is a 1.31-inch 2K × 2K (2048 × 2048) 1:1 square full-color Micro-OLED (OLEDoS) display engine designed for project-based developments and advanced optical systems. Its large-format square active area maximizes field-of-view (FOV) coverage in specialized near-eye and custom lens setups.
Powered by a high-bandwidth MIPI C-PHY / D-PHY interface, it supports 24-bit/16-bit RGB888 input with low power consumption. Featuring adjustable brightness from 50 to 3000+ cd/m², PSMV-DP-015 is ideal for high-end custom near-eye optics, industrial visualization, and tactical display systems.
1.31″ 2K×2K Square Full-Color Micro-OLED Display Module (2048×2048) PSMV-DP-015
Key Technical Specifications
| Parameter | Specification | Notes / Details |
| Product Code | PSMV-DP-015 | Key Model / Project-Based Platform |
| Display Technology | Micro-OLED Display (OLEDoS) | Monolithic Silicon CMOS Architecture |
| Active Size | 1.31 inch | Large-format micro-display viewport |
| Native Resolution | 2048 × 2048 (2K × 2K) | Ultra-dense 4-megapixel layout |
| Aspect Ratio | 1:1 | Symmetrical square aspect ratio |
| Color Spectrum | Full Color | Deep black levels & vibrant saturation |
| Luminance Range | 50 ~ 3000+ cd/m² | Dynamically adjustable output |
| Video Interface | MIPI-C/D PHY | High-speed low-power PHY signaling |
| Input Format & Depth | RGB888 (24-bit / 16-bit) | Crisp color processing |
Engineering Advantages
- Large-Format 1.31″ Square Viewport
- The enlarged 1.31″ active area reduces structural eye-relief constraints and optical magnification demands, allowing custom lens systems to achieve immersion without edge distortion.
- Flexible MIPI C/D-PHY High-Speed Interfacing
- Easily connects with modern high-performance application processors and FPGA platforms, ensuring smooth rendering of high-frame-rate 2K video streams.
- Tailored for High-End Custom Integration
- Engineered specifically for project-based optical innovations, backed by dedicated driver boards (e.g., BK-008) and custom optical path matching.
Target Applications
- High-Resolution Near-Eye Displays: Next-generation VR/MR optical combiners, custom head-mounted display (HMD) platforms, and wide-FOV optics.
- Advanced & Custom Optical Systems: Specialized optical research, high-magnification viewfinders, and custom projection assemblies.
- Special Industry & Tactical Displays: Professional flight simulation, medical visualization units, and military-grade observation terminals.
Ecosystem & Evaluation Kit
- Evaluation Hardware: Supported by BK-008 development and driver board for quick system bringing-up and optical validation.
- Custom Integration Support: Full optical alignment matching and custom housing design services available upon project budget and sample verification.
