Product Overview (Model: PSMV-DP-008)
PSMV-DP-008 is a classic 0.60-inch SVGA full-color silicon-based Micro-OLED (OLEDoS) microdisplay module designed for robust optical observation and industrial imaging applications. Delivering an 800 × 600 pixel layout in a standard 4:3 aspect ratio, it balances active screen size with excellent optical efficiency for direct-view eyepieces.
Featuring dual digital signal support (TTL / LVDS), the module allows seamless interfacing with legacy video processing boards, custom FPGAs, and robust industrial display controllers. With flexible customization options for hardware integration, PSMV-DP-008 serves as a versatile display solution for thermal imaging viewfinders, tactical scopes, and wearable inspection gear.
Key Technical Specifications
| Parameter | Specification | Notes / Details |
| Product Code | PSMV-DP-008 | Customization Available / OEM Ready |
| Display Technology | Micro-OLED Display (OLEDoS) | Single-Crystal Silicon CMOS Backplane |
| Diagonal Size | 0.60 inch | Standard optical viewport format |
| Resolution | 800 × 600 (SVGA) | Crisp 4:3 resolution |
| Aspect Ratio | 4:3 | Optimized for direct-view optics |
| Color Spectrum | Full Color | High contrast & deep black levels |
| Interface Options | TTL RGB / LVDS | Dual signal mode flexibility |
| Integration Status | Modular Engine | Custom housing & driver options |
Core Advantages & Features
- Optically Optimized 4:3 Canvas
- The 0.60″ active area provides an easy optical target for medium-to-wide FOV eyepieces without requiring extreme optical magnification.
- Dual TTL / LVDS Signaling
- Accommodates long-distance signal routing (LVDS) or direct controller connection (TTL), lowering board redesign costs.
- Tailored OEM Customization
- Fully customizable flex cables (FPC), driver board footprints, and glass pinouts to meet specific structural enclosures.
Target Applications
- Thermal Sights & Night Vision Scopes: Monocular and binocular thermal viewfinders, hunting optics, and tactical sights.
- Industrial & Technical Viewfinders: Inspection instrumentation, endoscope display units, and optical measurement devices.
- Wearable Display Terminals: Smart helmet viewports, field maintenance HMDs, and tactical data overlays.
